The Electroboat TPA3118 PBTL Mono Digital Amplifier Board leverages Texas Instruments' TPA3118 Class-D IC to produce high power output in a surprisingly small footprint. Utilizing Parallel Bridge-Tied Load (PBTL) configuration, the stereo channels are tied in parallel internally to function as a single-channel (mono) driver—significantly increasing current capability, lowering output impedance, and maximizing output power.

This board provides low noise distortion (THD+N) along with built-in thermal and over-current protection circuitries. Operating with higher than 90% energy efficiency, it generates minimal heat during sustained playback, removing the necessity of bulky external heatsinks. Simply hook up a DC power source (such as a 12V or 24V adapter or battery pack), an audio signal input, and your speaker terminals to achieve powerful audio amplification.

Key Features and Benefits

• PBTL Mono Mode Output: Combines output channels to deliver up to 60W of high-current audio to a single speaker or subwoofer.

• Wide Operating Voltage Range (DC 4.5V–24V): Operates on standard 12V, 19V, or 24V power supplies as well as lithium battery packs.

• High Efficiency (>90%): Minimal thermal loss allows long operational hours on battery setups without requiring external heat dissipation fans.

• Integrated Circuit Protection: Built-in protection against over-voltage, under-voltage, over-temperature, DC detection, and short circuits.

• Mute & Standby Interface: Includes dedicated solder/header pads to easily connect external switch control for mute and low-power standby modes.

Technical Specifications

How to Use

1. Power Connection: Connect a regulated DC power source (12V–24V) to the VCC (+) and GND (-) terminals on the board.

2. Audio Input Connection: Connect your line-level audio input (from a Bluetooth receiver board, AUX jack, or MP3 decoder) to the IN and GND pads.

3. Speaker Wire Connection: Connect a 4-ohm or 8-ohm speaker directly across the SPK+ and SPK- terminals.

4. Power On: Apply power. Ensure power supply current matches requirement (at least 3A–5A recommended at 24V for peak 60W performance).

Applications

• DIY Portable Bluetooth Speakers & Boomboxes

• Dedicated Active Subwoofer Power Amplifiers

• Vehicle & Marine Audio System Upgrades

• Public Address (PA) and Intercom Sound Amplifiers

• Arcade Machines, Kiosks, and Smart Home Audio Notifications

Package Includes

• 1 x TPA3118 PBTL Mono Digital Amplifier Module 1x60W
