The DIY 2-Wheel Wooden Chassis Robotic Car Kit is a versatile educational platform designed for students, educators, hobbyists, and robotics enthusiasts. Crafted from premium high-density laser-cut wood, the chassis offers an eco-friendly, easy-to-customize alternative to acrylic or metal chassis plates. The wood surface allows easy drilling, gluing, painting, and mounting of various sensors, microcontrollers, and motor drivers.

The kit includes two high-torque $3\text{V}-6\text{V}$ Dual-Shaft BO (Battery Operated) DC Gear Motors equipped with durable rubber-tread wheels for maximum traction on smooth surfaces. A low-friction omnidirectional front caster wheel provides smooth 360∘ differential steering and rotation. Pre-cut mounting slots allow seamless integration of popular microcontrollers (Arduino Uno, ESP32, Raspberry Pi Pico), motor drivers (L298N, L293D), ultrasonic distance sensors, line-tracking sensor arrays, and servo motors.

Key Features and Benefits

• Durable & Customizable Wooden Base Plate: Precision laser-cut wood with pre-drilled mounting slots for boards, sensors, switches, and battery holders.

• Dual High-Torque BO Gear Motors: $3\text{V}-6\text{V}$ DC gear motors supply efficient power and speed for indoor robotic navigation.

• Omnidirectional Front Caster Wheel: Smooth 360∘ swivel caster ensures smooth differential turning and balanced 3-point contact.

• High-Grip Rubber Wheels: $65\text{mm}$ wheels with textured rubber tires deliver excellent surface traction and shock absorption.

• Complete Assembly Hardware Included: Ships with motor mounting brackets, brass standoffs, nuts, bolts, and a $4\times \text{AA}$ battery holder.

• Ideal STEM & Educational Tool: Excellent hands-on kit for learning basic electronics, soldering, motor control, and embedded programming.

Technical Specifications

Assembly Overview & Motor Wiring Guide

1. Recommended Wiring Diagram:

                        +----------------------------+
                        |  4xAA Battery Holder (6V)  |
                        +--------------+-------------+
                                       |
                   +-------------------+-------------------+
                   | Positive (+)                      | Negative (-)
                   v                                   v
        +---------------------------------------------------------+
        |                 L298N / L293D Motor Driver              |
        +---------------+-------------------------+---------------+
                        |                         |
         Motor A Output |                         | Motor B Output
                        v                         v
               [ Left BO Motor ]         [ Right BO Motor ]

2. Component Placement Layout:

               +---------------------------------------------------+
               |               [ Front Caster Wheel ]              |
               |                                                   |
               |   (Pre-cut slots for Ultrasonic / IR Sensors)    |
               |                                                   |
               |         [ Arduino / ESP32 Controller ]            |
               |                                                   |
               |          [ Motor Driver Module L298N ]            |
               |                                                   |
               |  [Left Motor/Wheel]           [Right Motor/Wheel] |
               |                                                   |
               |              [ 4xAA Battery Holder ]              |
               +---------------------------------------------------+

Applications

• Obstacle Avoidance Rovers: Mounting an HC-SR04 ultrasonic sensor on a servo for autonomous navigation.

• Line Follower Robots: Attaching a $2\text{-channel}$ or $4\text{-channel}$ IR sensor array to follow black/white tracks.

• Bluetooth / Wi-Fi Remote Control Cars: Interfacing HC-05 Bluetooth or ESP32 Wi-Fi for smartphone control.

• STEM & Robotics Classroom Workshops: Hands-on teaching aid for school and college engineering projects.

Package Includes

• 1 x Laser-Cut Wooden Main Chassis Plate

• 2 x Dual-Shaft BO DC Gear Motors ($3\text{V}-6\text{V}$)

• 2 x $65\text{mm}$ Rubber Wheels with D-hole Hubs

• 1 x Mini Omnidirectional Caster Wheel

• 1 x $4\times \text{AA}$ Cell Battery Holder with Wires

• 4 x Acrylic/Metal Motor Fastening Brackets

• 1 x Complete Set of Screws, Nuts, and Brass Standoffs

Shipping & Delivery

• Free shipping on orders above ₹999 across India

• Dispatched within 1-3 business days

• Expected delivery: 3-7 business days depending on location
