Detailed Description:

The CD4026 IC is a CMOS decade counter with decoded 7-segment display output. It counts from 0 to 9 and directly drives a common-cathode 7-segment display, eliminating the need for external decoders or complex logic circuits. It accepts clock pulses at its input and automatically increments the count with each pulse.

It features carry-out, blanking input, and display enable functions and works across a wide voltage range from 3V to 15V, making it compatible with both CMOS and TTL logic systems. The DIP-16 package allows easy use in breadboards and custom PCBs.

Key Features:

• 0–9 decade counter with 7-segment decoder

• Drives common-cathode 7-segment displays directly

• Low power CMOS logic

• Wide operating voltage range: 3V–15V

• Carry-out pin for cascading multiple ICs

• Display enable and blanking inputs

• Easy to use with Arduino or 555 Timer

• DIP-16 package for prototyping

Technical Specifications:

How to Use:

1. Connect Vdd to 5V/12V, Vss to GND

2. Connect clock input (pin 1) to a pulse source (e.g., 555 timer or Arduino)

3. Connect segment output pins (a–g) to 7-segment display

4. Use carry-out to link to a second CD4026 for multi-digit counters

5. Connect Display Enable (DE) and Blanking (BI) appropriately

Applications:

• Digital counters (event, object, pulse)

• Electronic clocks and timers

• 7-segment display drivers

• Tally counters

• Scoreboards, stopwatches, and meters

• Arduino-based digital displays

Package Includes:

• 1 × CD4026 IC – 7-Segment Display Driver with Counter (DIP-16)
