Detailed Description:

The 47pF ceramic disc capacitor is a high-stability, low-loss capacitor commonly used in oscillator circuits, signal coupling, and RF applications. It offers excellent performance at high frequencies and is ideal for use with crystal oscillators (e.g., 16MHz or 20MHz crystals) in ATmega328P and Arduino-based boards.

Its compact radial-lead, through-hole design allows easy placement on breadboards and PCBs. With a typical voltage rating of 50V, this capacitor provides a reliable solution for low-voltage analog and digital circuits.

Key Features:

• Capacitance: 47 picofarads (pF)

• Type: Ceramic disc capacitor

• Tolerance: ±5% (standard)

• Voltage Rating: 50V DC

• Lead Type: Through-hole / radial

• Stable at high frequencies

• Ideal for oscillator and timing circuits

• Compatible with Arduino and ATmega crystal setups

Technical Specifications:

How to Use:

1. Use in parallel with a crystal oscillator (usually two capacitors, one from each XTAL pin to GND)

2. Insert leads into breadboard or solder into PCB

3. Suitable for timing circuits, filter networks, or coupling/decoupling

4. Can be paired with Arduino, ATmega, or PIC MCUs

Applications:

• Crystal oscillator circuits (e.g., 16 MHz, 20 MHz)

• High-frequency analog and RF circuits

• Microcontroller clock timing

• Coupling and decoupling signals

• Capacitive sensor circuits

• Filter and tuning circuits

Package Includes:

• 1 × 47pF Ceramic Disc Capacitor – 50V, ±5%, Through-Hole
