Detailed Description:

The 16-pin IC base socket is a dual-in-line (DIP) socket used for securely mounting 16-pin ICs such as L293D motor driver, CD4017 decade counter, ULN2003 relay driver, and logic gates. It offers a solder-free method of inserting and replacing ICs during prototyping, repairs, or circuit upgrades.

Its tin-plated contact pins ensure excellent conductivity, while the thermoplastic body withstands soldering heat. The standard 2.54mm pitch spacing fits perfectly into most PCBs and breadboards.

Key Features:

• Standard 16-pin dual inline (DIP) configuration

• Compatible with ICs like L293D, ULN2003, CD4017, 74-series ICs

• Tin-plated phosphor bronze contacts for secure connection

• Prevents IC overheating during soldering

• Durable high-temp black thermoplastic body

• Fits all 2.54mm pitch PCBs and breadboards

• Easy IC replacement, swapping, or testing

Technical Specifications:

How to Use:

1. Insert and solder the IC base into your PCB or plug into breadboard

2. Align your 16-pin DIP IC with the socket and press in gently

3. Ensure pin 1 matches the socket notch

4. Use for easy IC replacement and safe solder-free operation

Applications:

• Motor driver circuits (e.g., L293D)

• Relay driver arrays (e.g., ULN2003)

• Counter/decade logic ICs (CD4017, 74HC series)

• Embedded systems and robotics

• DIY electronics kits and prototyping boards

• Electronics repairs and development platforms

Package Includes:

• 1 × 16-Pin IC Base Socket – DIP Type
  (IC not included – sold separately)
